Designs (71)

71 Results - Page 1/8 |< < 1 2 3 4 5 > >|

XRP7714EVB-DEMO-2P-KIT: 4 Chan, 4A, 4.5 ~ 25V in

Manufacturer: Exar Corporation

The XRP7714EVB-DEMO-1, XRP7714EVB-DEMO-2, and the XRP7714EVB-DEMO-2P demo boards are complete, working, four channel, power systems measuring either 2”x2”, or 2”x2.5” capable of delivering over 35 watts. They provide 3.3V, 2.5V, 1.8V, and 1V at a maximum of 4 amps per channel. The 2.5V, 1.8V, and 1V supplies can be adjusted in 50mV increments, and the 3.3V supply is adjustable in 100mV increments.…

View Design

RD-171 LM5001: +/- 5V @ 250mA, 10 ~ 30V in

Manufacturer: Texas Instruments

A very low noise differential power supply for split rail systems requiring low noise +5V and -5V (higher or lower voltage is possible). This design is fully isolated and capable of floating to over 500V differential from Vin to Vout (higher is possible).

The LM5001 IC is a fully integrated flyback regulator which performs all of the current mode control for tight regulation and tra…

View Design

STEVAL-ISA050V1: DDR2/3 Supply

Manufacturer: STMicroelectronics

The PM6641 demonstration board is a monolithic voltage regulator (VR) module with internal power MOSFETs, specifically designed to supply DDR2/3 memory and chipset in ultramobile PC and real estate constrained portable systems.

View Design

DC1453A: 1.8V & 3.3V @ 4A, 4.5 ~ 28V in

Manufacturer: Linear Technology/Analog Devices

Demonstration circuit 1453A features the LTM®4619EV, the high input voltage, high effi ciency, high density, dual 4A step-down power module. Derating is necessary for certain VIN, VOUT, and thermal conditions.

The two outputs are interleaved with 180° phase to minimize the input ripple
and reduce the input capacitors. A minimum design only requires the bulk input and output ca…

View Design

LMR24220RB: 3.3V @ 2A, 1.2V @ 1A, 1.8V @ 1A, 5 ~ 32V in

Manufacturer: Texas Instruments

The LMR24220 Multi-Rail reference board implements an extremely compact solution. It is designed to convert from 12V or 24V rails down to typical point-of-load voltages of 3.3V, 1.8V and 1.2V. This design utilizes an LMR24220 Nano Regulator and two LMZ10501 Nano Modules to demonstrate a complete solution for space constrained multi-rail applications.

View Design

ADP5050-EVALZ: 5 Ch., 4.5 ~ 15V in, Buck/LDO

Manufacturer: Analog Devices Inc.

This user guide describes the hardware and software for the evaluation of the ADP5050/ADP5052 and includes detailed schematics and printed circuit board (PCB) layouts.

The ADP5050/ADP5052 evaluation board combines four high performance buck regulators and one 200 mA LDO in a 48-lead LFCSP package to meet the demanding performance and board space requirements. The ADP5050/ADP5052 eval…

View Design

DC1582B-A 50-400mV Ultralow Input Voltage Boost

Manufacturer: Linear Technology/Analog Devices

Demonstration Circuit 1582B featuring the LTC3108 is a highly integrated DC/DC converter optimized for harvesting and managing energy from extremely low input voltage sources such as thermoelectric generators (TEG). The step-up topology operates from input voltages as low as 20mV.

The DC 1582B Demonstration Circuit has been optimized for low start-up voltage with a 100:1 turns ratio …

View Design

DC1280A: +12V @ 0.3A, -12V @ 0.2A, 4.5 ~ 10V in

Manufacturer: Linear Technology/Analog Devices

Demonstration circuit 1280A is a dual output converter featuring the LT3471EDD in Boost and Inverter configurations. Both converters are powered from the same 4.5V to 10V input source. The Boost converter puts out 12V at 300mA and the Inverter -12V at 200mA. The demo circuit demonstrates small size and low component count.

View Design

ADP5052-EVALZ: 1.2V @ 4A, 3.3V @ 4A, + 1.8V, 5V, 2.5V @ 1.2, 1.2, 0.2A

Manufacturer: Analog Devices Inc.

This user guide describes the hardware and software for the evaluation of the ADP5050/ADP5052 and includes detailed schematics and printed circuit board (PCB) layouts.

The ADP5050/ADP5052 evaluation board combines four high performance buck regulators and one 200 mA LDO in a 48-lead LFCSP package to meet the demanding performance and board space requirements. The ADP5050/ADP5052 eval…

View Design

ADP5053-EVALZ: 4Ch Buck, Up to 4A, 4.5 ~ 15V in

Manufacturer: Analog Devices Inc.

This user guide describes the hardware and software for the evaluation of the ADP5051/ADP5053, including detailed schematics and printed circuit board (PCB) layouts. The ADP5051/ADP5053 evaluation board combines four high performance buck regulators and supervisory in a 48-lead LFCSP package to meet demanding performance and board space requirements.

View Design
